Shure SLXD24D/B58 Dual-Channel Digital Wireless Handheld Microphone System

Description

The SLXD24D/58 Wireless System delivers transparent, 24-bit digital audio and rock-solid RF performance for a wide range of applications, from day-long presentations to nighttime performances. Operate up to 32 compatible systems per 44 MHz band, with easy setup and optional rechargeability accessories for wireless excellence, wherever required. Ships with SLXD4D dual-channel receiver and two SLXD2/B58 handheld transmitters with antenna and rackmount accessories and 4 AA batteries.

Featuring two Beta® 58 Supercardioid Dynamic Microphone capsules on SLXD2 handheld wireless transmitters, the SLXD24D/B58 provides transparent digital audio and rock-solid RF stability for lecture halls and live performances.

Features

The SLX-D operates in the UHF band to transmit high-quality, 24-bit digital audio with over 120 dB of dynamic range for crisp, detailed sound. It utilizes Digital Predictive Switching Diversity to protect the transmission from interference and deliver a solid, reliable RF signal without dropouts.

This configuration includes two SLXD2 handheld transmitters, each featuring an interchangeable microphone capsule design and equipped with a Beta 58A dynamic capsule. The Beta 58A has a supercardioid pickup pattern that focuses on speech, helping to reduce feedback on loud stages. The lightweight metal transmitters feature a selectable 1/10mW RF power output and a transmission range up to 330′. Power is supplied by two AA batteries or an SB903 rechargeable battery (available separately) for up to 8 hours.

The all-metal, rackmount SLXD4D receiver features an intuitive LCD interface with meters for RF, battery status, and audio outputs. It also offers 60 dB of gain control, and both mic/line XLR and 1/4″ instrument outputs for each channel. Additional features include automatic frequency scanning and IR sync to easily link the transmitter and receiver to the same frequency.

With up to 32 mic channels available at the same time, the SLX-D is ready to expand as your needs grow. What’s more, setting up multiple systems is made fast and easy via the Ethernet port, which links them together for quick, coordinated frequency scans from a single receiver.

• With durable aluminum housing, the SLXD2 handheld transmitter offers a lightweight design that’s comfortable to hold, and it features an LCD to show essential information.
• The Beta 58A dynamic microphone capsule handles high SPL levels and has a tailored frequency response that accentuates clarity of vocals; a tight supercardioid pattern ensures high gain before feedback, maximum isolation from other sound sources, and minimum off-axis tone coloration.
• The transmitter’s interchangeable capsule design allows you to choose the ideal capsule for your application. Shure offers a variety of optional dynamic and condenser mic capsules with varying pickup patterns—capsules include the Beta 87A, SM58, and KSM8.

SLXD2 Digital Wireless Handheld Transmitter

Versatile and rugged, the SLXD2 features industry-leading digital wireless technology and design. Sync it easily to the SLXD4D wireless receiver using its IR scan and sync functionality. Choose from a vast selection of interchangeable vocal microphone capsules to perfectly fit your application. Its all-metal construction makes it a hardy component in your audio arsenal.

SLXD4 Digital Wireless Receiver

Experience the freedom of wireless performance with the SLXD4. From lecture-hall presentations to worship services to musical concerts, the SLXD4 is the perfect choice for confident, reliable wireless audio, syncing easily to your choice of wireless transmitters. This receiver boasts a rugged, all-metal construction that makes it a durable choice for day-long presentations or all-night performances. Its half-rack size makes it easy to integrate into any preexisting sound setup.

In The Box

• 1 dual channel receiver
• 2 handheld transmitter with mic cartridge
• 2 mic clip
• 2 brass adaptor for the mic clip
• 4 AA batteries
• 2 1/4 wave antennas
• 2 bulkhead adapters
• 2 22″ BNC cables
• 1 power supply
• 2 black vinyl zippered bag
• 2 rack mount bracket (short)
• 1 hardware kit
• 1 quick start guide
• 1 warranty
• 4 adhesive foot

Specifications
