Relacart Podcast+ Podcast Production Studio
Key Features:
- Simulate On-Site Reverberation
- Internal Play Switch
- Custom Sound Effects
- 48v Phantom Power Switch
- MIC PRIOR Switch (Ducking)
- Intelligent Noise Reduction
Description
Description
Podcast+ is a audio mixer specifically designed for live streaming app. It integrates live streaming application functions such as mixing, sound effects, etc. It can be connected to two mobile phones or computers simultaneously and transmit audio to live streaming devices through digital audio technology. Lightweight and easy to carry,the panel layout is simple, and the functional differentiation is clear and easy to understand. Equipped with Type-C interface to charge, which can realize charging while broadcasting, eliminating the trouble of live broadcast battery life. Podacast+ is suitable for mobile phones, computers, etc.
- Sample Rates：24 – bit, 48 KHz
- Input Crosstalk：＜-120db @ 1KHz (Adjacent Channels)
Features
Functional Features:
| Simulate On-site Reverberation | Podcast+ has 16 simulated live reverb effects internally, which can be selected according to the live content to enhance the atmosphere of the live broadcast. |
|---|---|
| Internal Play Switch | When the Internal Play switch is turned on, the input audio from the Type-C will not be sent back to the Type-C output, eliminating echo issues. |
| Custom Sound Effects | Comes with 9 built-in sound effects, which can be replaced via USB. |
| 48v Phantom Power Switch | It can provide power for microphone port for live broadcast condenser microphone. |
| MIC PRIOR Switch (Ducking) | When the MIC PRIOR switch is turned on, it automatically reduces the volume of background music and sound effects when there is audio input from the microphone. |
| Intelligent Noise Reduction | When the noise reduction switch is turned on, it reduces the ambient noise picked up by the microphone. |
Specifications
| Sample Rates | 24 – bit, 48 KHz |
|---|---|
| Frequency Response | 20Hz to 20 KHz |
| System Delay | 1.5ms |
| T.H.D. | ＜0.05％ |
| Input Crosstalk | ＞65dB @ 1KHz (Adjacent Channels) |
| S/N Ratio | 90dB single channel – fader max (A-weighted) |
| Dynamic Range | 90dB single channel – fader max (A-weighted) |
| Common Mode Rejection Ratio | ＞60dB @ 1 KHz |
| MIC Impedance | 3kΩ（XLR Balance); 6.6kΩ（1/4） |
| MIC Gain | 0 to 45 dB（XLR) |
| Power Supply | DC 5V（1A） |
| Dimensions (mm) | 260（L）×230（H）×89（D） |
| Weight | 1.5kg |
