Next Audio C5 Pro 5″ Premium Ceiling Speaker [100V|8Ω]
Key Features
100V / 8Ω Input
The integrated transformer allows you to use the speaker at 100V line or low impedance 8Ω depending on the needs of your installation.
Frameless Design
The frameless design allows you have an unobtrusive sound source, keeping the architectural requirements of your installation.
Environment Equalizer
You can use the Environment Equalizer to automatically adjust the sound, for the area where the ceiling speaker is installed.
HF Driver Protection
The HF Driver Protection gives the speaker a higher protection on the High Frequency Driver against unexpected audio peaks during music reproduction.
Detachable Logo
The logo is detachable, which means you can remove it if a clean design is needed on your installation.
Magnetic Grille
The magnetic grille allows a very easy installation without screws. You just need to install your speaker on the wall or ceiling and place the magnetic grill that will fit automatically.
Description
The C5 Pro is a ceiling speaker with an elegant design, intended to be installed in false ceilings, walls or panels. It combines modern style with outstanding audio performance that fills your room with powerful warm and richly detailed sound. The integrated transformer allows you to use the C5 Pro on 100V line or low impedance 8Ω depending on your installation needs.
Features
Easy Install
The fastening system allows a simple installation in your ceiling or wall and does not require high technical skills for a successful result, being a quick and easy installation.
Elegant Design
With their ultra-thin design the C5 Pro speakers fits all your installations where the design is important.
Adjustable Tweeter
You can adjust the tweeter, having the sound exactly where you need it, covering the exact places you need.
Powerful Sound
Magnetic Grill
Environtment Equalizer
Specifications
| Product Type | 2-Way Premium Ceiling Speaker (8Ω/100V) |
|---|---|
| RMS Power | 40W (8Ω) |
| Sensitivity (1W, 1m) | 90dB |
| Transformer Taps 70V | 1.25W | 2.5W | 5W |
| Input Connectors | Gold Plated Binding Posts (8Ω) / Quick Release Connector (100V) |
| Grille | White Frameless Magnetic Grille (Paintable) | Detachable Logo |
| Fixation | Eye Bolt for Suspension | Bracket for Wall Mount (not included) |
| Cutout Diameter | 179mm (7″) |
| Fixation | Plastic Clamps for Ceiling Fixation |
| Accessories | Black Frameless Magnetic Grille (not included) |
| Frequency Response (-6dB) | 70Hz – 20kHz |
| Program Power | 80W (8Ω) |
| Maximum SPL (calculated) | 109dB |
| Low Frequency Driver | 5.25″ Reinforced Polymer Cone Woofer |
| Recommended Amplifier | A40 | A200 | MX120 | MX350 |
| IP Rating | Indoor Use |
| Mounting Depth | 78mm (3.1″) |
| Net Weight | 1.2kg (2.6lb) |
| Nominal Coverage (-6dB) | 100° Conical |
| Transformer Taps 100V | 2.5W | 5W | 10W |
| High Frequency Driver | 0.75″ Pivoting (±10°) Titanium Dome Tweeter |
| Special Features | Adjustable Environment Equalizer (±3dB) |
| Dimensions (ØxD) | 204mm x 78mm (8″ x 3.1″) |
| Wall / Ceiling Thickness | 3mm to 15mm (0.12″ to 0.59″) |
| Shipping Weight | 1.5kg (3.3lb) |
