Canon imageCLASS LBP623Cdw
Inspire with Vibrant Colour
With vibrance in colour, high print quality and wireless connection, boost efficiency with the imageCLASS LBP623Cdw.
- Print Speed (A4): Up to 21 ppm (mono/colour)
- First Print Out Time (A4): Approx. 10.4 / 10.5 sec (mono/colour)
- Print Resolution: Up to 1,200 x 1,200 dpi (equivalent)
- Gigabit Ethernet, Wireless, Direct Connection
- Recommended Monthly Print Volume: 250 – 2,500 pages
Description
Inspire with Vibrant Colour
With vibrance in colour, high print quality and wireless connection, boost efficiency with the imageCLASS LBP623Cdw.
- Print Speed (A4): Up to 21 ppm (mono/colour)
- First Print Out Time (A4): Approx. 10.4 / 10.5 sec (mono/colour)
- Print Resolution: Up to 1,200 x 1,200 dpi (equivalent)
- Gigabit Ethernet, Wireless, Direct Connection
- Recommended Monthly Print Volume: 250 – 2,500 pages
Features
5-line LCD Display
Navigate and configure the printer setting easily with the 5-line LCD display. Information can be displayed at a glance, facilitating easy device management and maintenance.
Wireless Freedom
Do away with unsightly cables as the imageCLASS LBP623Cdw can be shared wirelessly within your network. The printer also has built in Access Point capability, enabling easy connection to mobile devices without a router.
Mobile Printing Solutions
With Canon’s latest mobile business solution, you can print documents, photos and web pages with just one app. Click here to find out more!
Auto Duplex Printing
Do your part for the environment with the automatic duplex printing feature. Print on both sides to reduce paper wastage while reducing the carbon footprint and operational costs.
Versatility
The LBP623Cdw comes with PCL and Adobe® PostScript® 3™ for added compatibility with different business applications and print environment.
Secure Print
The native Secure Print feature enables you to print documents securely at no extra costs, preventing confidential printouts from being left unattended.
Minimal Maintenance
Enjoy fuss-free and low maintenance operation with Canon All-in-One toner cartridge design. Optional high capacity cartridge 054H is available for customer with high volume printing, reducing the frequency of replacing cartridge even further.
Direct USB Printing
Enjoy the convenience of direct printing from USB memory devices, in various file formats such as PDF, JPEG and TIFF.
Specifications
| Printing Method | Colour Laser Beam Printing |
| Print Speed | |
| A4 | 21 / 21 ppm (Mono / Colour) |
| Letter | 22 / 22 ppm (Mono / Colour) |
| 2-sided | 12 / 12 ipm (Mono / Colour) |
| Print Resolution | 600 x 600 dpi |
| Print Quality with Image Refinement Technology | 1,200 (eq.) x 1,200dpi (eq.) |
| Warm up Time (From Power On) | 13 sec or less |
| First Print Out Time (FPOT) | |
| A4 | Approx. 10.4 / 10.5 sec (Mono / Colour) |
| Letter | Approx 10.3 / 10.3 sec (Mono / Colour) |
| Recovery Time (From Sleep Mode) | 6.1 sec or less |
| Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
| Auto Duplex Print | Standard |
| Available Paper Size for Auto Duplex Print | A4, Letter, Legal, Foolscap, Indian Legal |
| Print Margins | 5mm – top, bottom, left and right (Envelope: 10mm) |
| Print Features | Poster, Booklet, Watermark, Page Composer, Toner Saver |
| Supported File Format for USB Direct Print | JPEG, TIFF, PDF |
Paper Handling
| Paper Input (based on 80g/m²) | |
| Standard Cassette | 250 sheets |
| Multi-Purpose Tray | 1 sheet |
| Maximum Paper Input Capacity | 251 sheets |
| Paper Output | 100 sheets |
| Paper Sizes | |
| Standard Cassette | A4, B5, A5, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal Custom (Min. 76.2 x 127.0mm to Max. 216.0 x 355.6mm) |
| Multi-Purpose Tray | A4, B5, A5, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card. Envelope: COM10, Monarch, C5, DL Custom (Min. 76.2 x 127.0mm to Max. 216.0 x 355.6mm) |
| Paper Types | Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope |
| Paper Weight | |
| Standard Cassette | 60 to 200g/m² |
| Multi-Purpose Tray | 60 to 200g/m² |
Connectivity & Software
| Standard Interfaces | |
| Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
| Wireless | Wi-Fi 802.11b/g/n (Infrastructure mode, WPS Easy Setup, Direct Connection) |
| Network Protocol | |
| LPD, RAW, WSD-Print (IPv4,IPv6) | |
| TCP/IP Application Services | Bonjour(mDNS), HTTP, HTTPS, POP before SMTP (IPv4,IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
| Management | SNMPv1, SNMPv3 (IPv4,IPv6) |
| Network Security | |
| Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC |
| Wireless | WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES) |
| Other Features | Department ID, Secure Print |
| Mobile Solution | Canon PRINT Business, Canon Print Service, Google Cloud Print™, Apple® AirPrint®, Mopria® Print Service |
| Compatible Operating Systems | Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008, Mac® OS X 10.9.5 & up*1, Linux*1 |
| Software Included | Printer driver, Toner Status |
General
| Device Memory | 1 GB |
| LCD Display | 5-line LCD |
| Dimensions (W x D x H) | 430 x 418 x 287mm |
| Weight | 14.0 kg |
| Power Consumption | |
| Maximum | 850W or less |
| Average (During Copy Operation) | Approx. 390W |
| Average (During Standby) | Approx. 8.5W |
| Average (During Sleep) | Approx. 0.8W (USB/ LAN / Wi-Fi) |
| Operating Environment | |
| Temperature | 10 – 30°C |
| Humidity | 20% – 80% RH (no condensation) |
| Power Requirements | AC 220 – 240V (+/-10%), 50/60 Hz (+/-2Hz) |
| Noise Levels *2 | |
| During Operation | Sound Pressure Level: 52 dB Sound Power Level: 69.4 dB |
| During Standby | Sound Pressure Level: inaudible Sound Power Level: 43 dB |
| Consumables*3 | |
| Toner (Standard) | Cartridge 054 BK: 1,500 pages (bundled: 910 pages) Cartridge 054 CMY: 1,200 pages (bundled: 680 pages) |
| Toner (High) | Cartridge 054H BK: 3,100 pages Cartridge 054H CMY: 2,300 pages |
| Monthly Duty Cycle*4 | 30,000 pages |
